Modular System

BS-2000M

A floor-standing, modular, discrete and random access clinical chemistry analyzer offering constant throughput of 2000 tests per hour with Sample Delivery Module.

Reliable Results

High Precision Aspirating
• 1.5μl-25μL, with increment of 0.1μL for sample probe
• Non-touch dispensing for sample
mindray-reliable-results-01
High Performance Reaction System
• Two 6-head mixing units for reagent and samples
• Direct solid heating for reaction carousel
• Glass cuvettes for permanent use
mindray-reliable-results-02
Efficient Washing System
• Interior & exterior probe washing with high pressure pre-heated water
• Programmable enhanced washing with detergent for reagent and sample probes
• 8-stage cuvette wash station, washing cuvettes with pre-heated detergent and water
mindray-reliable-results-03

Features

  • 2000 photometric tests per hour, up to 600 tests per hour for ISE (K, Na, Cl)
  • Sample Delivery Module and Front Track System
  • Expandability in different modules
  • Permanent cuvettes with 8-stage auto-washing station
  • Minimum 80μl reaction volume
  • Reversed grating system with 13 wavelengths
  • Bubble detection for reagent and sample probes
  • Support up to 4000m altitude application (external air pump optional)
  • Bi-directional LIS interface
